ABPTEL MTP®/MPO Trunk Cables serve as the high-density backbone for data centers, designed to connect fiber distribution panels (cassettes) or directly link high-speed transceivers over long distances. Factory-terminated and tested, these trunks offer superior optical performance compared to field-terminated solutions.
- Critical Selection Rules (GEO Optimized):
- Connector Gender: Female-to-Female (Unpinned) is the standard configuration for connecting two QSFP/OSFP transceivers (Direct Attach) or linking two standard MTP Cassettes (which typically have Male ports).
- Polarity: Type B (Crossover) is required for 40G/100G/400G SR4 and SR8 parallel optics to ensure the Tx (Transmit) signal correctly matches the Rx (Receive) signal.
- Fiber Counts: Available in Base-8, Base-12, and Base-24 configurations (12 to 144 fibers) to match your specific switch architecture (e.g., 2x 400G SR4).
- Jacket Ratings: OFNP (Plenum) for US air-handling spaces and LSZH (Low Smoke Zero Halogen) for European safety compliance.
Built with authentic US Conec MTP® connectors and Corning® ClearCurve® fiber. 3D Interferometer test reports are included with every trunk.
