Description
The ABPTEL SFP-25G-ZR 25GBASE-ZR SFP28 optical transceiver is designed for ultra-long-reach 25 Gigabit Ethernet applications. Operating at a wavelength of 1310nm, it delivers a link distance of up to 80km over OS2 single-mode fiber (SMF) with LC duplex connectors.
Equipped with electro-absorption modulated laser (EML) transmitter and SOA & PIN receiver, the module ensures superior sensitivity and performance even across long-haul connections. With support for digital diagnostics monitoring (DOM/DDM), users can track key parameters such as optical power, voltage, temperature, and bias current in real time.
This hot-pluggable SFP28 transceiver complies with MSA, IEEE 802.3by, and RoHS standards, ensuring full interoperability with Cisco switches, routers, and NICs. The ABPTEL SFP-25G-ZR offers a cost-effective alternative to OEM optics, delivering reliable, energy-efficient (<2.5W) 25Gbps connectivity for data center interconnects, metropolitan networks, telecom backbones, and enterprise infrastructure.
Specifications
| Parameter | Specification |
|---|---|
| Form Factor | SFP28 |
| Data Rate | 25 Gbps |
| Wavelength | 1310nm |
| Max Distance | 80km over OS2 SMF |
| Connector | LC Duplex |
| Cable Type | OS2 Single-Mode Fiber |
| Transmitter Type | EML |
| Receiver Type | SOA & PIN |
| TX Power | 2 ~ 7dBm |
| Receiver Sensitivity | < -28dBm |
| Power Consumption | < 2.5W |
| Modulation Format | NRZ |
| DDM/DOM | Supported |
| Bit Error Ratio (BER) | 1E-12 |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Compliance | SFP28 MSA, IEEE 802.3by, RoHS |
Key Benefits
- Ultra-long reach: Supports up to 80km over OS2 SMF, ideal for metro and backbone networks.
- Cisco compatibility: Fully interoperable with Cisco switches, routers, and NICs.
- High performance optics: EML transmitter + SOA/PIN receiver for enhanced sensitivity and stability.
- Energy-efficient: Low power consumption <2.5W, reducing OPEX.
- Real-time monitoring: DOM/DDM support for key operational parameters.
- Cost-effective alternative: ABPTEL provides reliable performance at a competitive price.
